Reimagining Connectivity from Space
Scalable, Cellular-Class Performance for SCS (Supplementary Coverage from Space)
Scalable, Cellular-Class Performance
ClusterSat is redefining space-based communications through its innovative fractionated satellite architecture. By integrating advanced MIMO (Multiple-Input Multiple-Output) technologies, ClusterSat enables high-capacity, low-latency direct to device connectivity.
This scalable and resilient system is designed to meet the growing demand for seamless, broadband access—anywhere on Earth—by leveraging synchronized, modular satellite units that function as one phased array antenna.
Fractioned Satellite Architecture
-
3D fractionated LEO constellation (~600 km altitude) with inter-satellite links.
-
Scalable deployment — from a few to hundreds of satellites; number of satellites = number of active user.
-
Satellites spaced ~100m apart.
-
Operating below 6 GHz.
-
Main satellite handles most digital processing; ancillary satellites act as synchronized remote radio heads (RRHs), lighter and simpler.
-
Backhaul, beam management, and upper-layer processing compatible with legacy standards (e.g., 3GPP NTN).
